Rugged and reliable

With best-in-class lifting capability, superior range and outstanding performance, the multi-role AW109 Trekker enables operators to tackle even the most demanding missions. The twin-engine AW109 Trekker is a flexible, rugged and reliable aircraft that offers a high payload and a spacious cabin that can be reconfigured quickly, making it ideally suited to a wide range of applications.

Missions & Features

Technical data

Weight (MGW)

Internal loads

3,175 kg - 7,000 lb

Weight (MGW)

External loads

3,350 kg - 7,385 lb

Powerplant

2 x Pratt & Whitney

Canada PW207C

Overall length*

12.96 m - 42 ft 06 in

*Rotor turning

Overall height

3.60 m - 11 ft 09 in

Rotor diameter

10.83 m - 35 ft 06 in

Capacity

Crew 1-2

Passengers Up to 6

Max Cruise Speed (@5,000 FT, ISA, MGW, MCP)

274 KM/H - 148 KTAS

HIGE (ISA, MGW, TOP)

4,609 m - 15,120 ft

HOGE (ISA, MGW, TOP)

2,926 m - 9,600 ft

MAX RANGE (@5,000 FT, ISA, MGW)

828 KM - 447 NM
with auxiliary fuel tanks - No reserve

678 KM - 366 NM
with auxiliary fuel tank - No reserve

MAX ENDURANCE (@5,000 FT, ISA, MGW)

4 h 19 min
with auxiliary fuel tanks - No reserve

3 h 32 min
with auxiliary fuel tank - No reserve
