AW101 – SAR - Helicopters

The AW101 embodies advanced design and technology coupled with long range and endurance, which provides operational persistence for all missions. The versatility of the AW101 platform and a full range of on-board equipment allow operators to configure the helicopter for a wide range of roles including Maritime, Battlefield/Personnel Recovery and SAR.

Missions & Features

Technical data

MAXIMUM GROSS WEIGHT

15,600 kg 34,390 lb

POWERPLANT

GE CT7-8E Turboshafts with FADEC

OVERALL LENGTH

22.83 m 74 ft 11 in

OVERALL HEIGHT

6.66 m 21 ft 10 in

ROTOR DIAMETER

18.60 m 61 ft 0 in

CAPACITY

2 pilots, 1 air crewman, 25+ troops on crashworthy seating

MAX CRUISE SPEED (ISA, MGW, SL, MCP)*

277 km/h 150 kt
* SL-MCP = Sea Level at Max Continuous Power

RATE OF CLIMB (ISA, MGW, SL, MCP)

9.5 m/s 1,880 ft/min

HIGE (ISA, MGW)

3,307 m 10,850 ft

MAX RANGE (@5,000 FT, ISA, MGW)*

1500 km 810 nm
*Twin Engine Cruise, No reserves, standard fuel tanks, 6,000 ft cruise

MAX ENDURANCE (@5,000 FT, ISA, MGW)*

7 h 40 min
*Twin Engine Cruise, No reserves, standard fuel tanks, 6,000 ft cruise
